Punch Knives

What do Industrial Punch Knives Mean?

The term “Industrial Punch Knives” refers to robust cutting tools designed for creating holes or specific shapes in various materials through a punching action in industrial applications. Unlike cutting blades that slice along a line, Industrial Punch Knives are pressed through the material to remove a piece, leaving behind a shaped opening. These knives are typically used in conjunction with a die, which supports the material and defines the shape of the punched-out piece. Industrial Punch Knives are employed across a wide range of manufacturing processes, including metalworking, paper converting, packaging, leather goods production, and textile manufacturing. They are valued for their speed, accuracy, and ability to create consistent shapes and holes in high volumes. Depending on their specific application and design, Industrial Punch Knives may also be referred to as “punch press tooling,” “stamping punches,” “piercing punches,” “die punches,” “forming punches (if shaping as well as cutting),” or “profile punches.”

Uses and Applications of Industrial Punch Knives

Industrial Punch Knives are essential tools in numerous industrial manufacturing processes:

• Metalworking: Creating holes of various shapes (round, square, oblong, custom) in sheet metal for fasteners, ventilation, or other functional or aesthetic purposes. They are used in punch presses and stamping machines.
• Paper Converting: Punching out shapes for labels, packaging materials, and decorative paper products. This includes creating perforations or tear lines.

• Packaging Industry: Manufacturing custom packaging inserts, cutouts for product placement, and features like hanger holes in cardboard or plastic packaging.

• Leather Goods Production: Punching holes for stitching, rivets, buckles, and decorative patterns in leather for belts, bags, shoes, and upholstery.

• Textile Manufacturing: Cutting out shapes for garment components, creating decorative patterns, or making holes for fasteners like grommets.
• Rubber and Gasket Manufacturing: Punching out gaskets, seals, and other rubber components with precise shapes.

• Food Processing: Creating specific shapes in food products or packaging materials.
• Medical Device Manufacturing: Punching out precise shapes from films, foils, and other materials used in medical devices and packaging.


The design, size, shape, material, and the force applied to Industrial Punch Knives are critical factors that determine the quality and efficiency of the punching operation, depending on the material being worked with and the desired outcome.

Common Materials for Industrial Punch Knives

The materials used to manufacture Industrial Punch Knives are selected for their hardness, wear resistance to withstand repeated high-force impacts, and toughness to prevent fracturing. Common materials include:

• High Carbon Steel: Offers good hardness and can be heat-treated to provide a durable cutting edge, suitable for punching softer materials.

• Tool Steels (e.g., D2, M2, A2, O1): Provide a superior balance of hardness, toughness, and wear resistance, making them suitable for a wider range of materials, including harder metals and abrasive materials. High-speed steel (HSS) like M2 is used for applications involving higher temperatures or cutting speeds.

• High Chromium Tool Steels: Offer excellent wear resistance, crucial for punching abrasive materials and extending the lifespan of the punches.

• Carbide (Tungsten Carbide): Provides exceptional hardness and wear resistance, ideal for high-volume production and punching very hard or abrasive materials, significantly extending tool life. Often used as inserts or tips on steel bodies.

• Powder Metallurgy Steels (PM Steels): Offer superior homogeneity and can be engineered for optimal wear resistance and toughness, particularly beneficial for complex punch geometries and demanding applications.


Heat treatment to achieve the desired hardness and temper is a critical step in the manufacturing process of Industrial Punch Knives. Coatings, such as Titanium Nitride (TiN), Chromium Nitride (CrN), or Diamond-Like Carbon (DLC), may be applied to further enhance surface hardness, reduce friction, and increase wear resistance, especially when working with sticky or abrasive materials.

Common Shapes of Industrial Punch Knives

Industrial Punch Knives come in a vast array of shapes and sizes, customized to create specific holes or forms. Common shapes and features include:

• Round Punches: For creating circular holes, available in various diameters.
• Square Punches: For creating square holes, with precise side dimensions.

• Oblong Punches (Slot Punches): For creating elongated, rectangular holes with rounded or straight ends.
• Rectangular Punches: For creating rectangular holes with specific length and width.
• D-Shaped Punches: For creating D-shaped holes, often used for specific mounting or fastening applications.
• Keyway Punches: For creating the internal grooves in pulleys or gears that fit onto a keyed shaft.
• Profile Punches (Forming Punches): Custom-shaped punches designed to create intricate outlines or forms in the material, often used in stamping or deep drawing processes in addition to simple punching.
• Louver Punches: Specialized punches that create angled, overlapping cuts to form louvers for ventilation.
• Notching Punches: Designed to remove material from the edge of a workpiece, creating notches of various shapes (V-notch, U-notch, square notch).
• Perforating Punches: Feature multiple small pins or shaped projections to create a series of holes or perforations for tearing or ventilation.

The design of the punch also includes the shank, which is the part that fits into the punching machine. Shanks come in various standards and sizes to match different press types. The cutting edge of the punch is precisely ground to ensure clean and accurate punching.

If you don’t find the blade you are looking for, we can also customize it. See our “Custom Blades” to learn how! Welcome to inquire!
